RS07 Skid Steer Loader
The Rippa RS07 is a heavy-duty skid steer loader designed for demanding material handling, construction, landscaping, municipal maintenance, snow removal, and multi-purpose site work. With a Kubota D1105 diesel engine, enclosed cab, strong hydraulic system, and high load capacity, the RS07 is built for users who need more power, comfort, and stability from a compact loader.
With a machine working weight of 1,230 kg, a rated safe load of 300 kg, and a maximum load capacity of 670 kg, the RS07 is designed for heavier-duty loading, carrying, digging, clearing, attachment work, and operation in demanding site conditions.
Key features include:
✔ Kubota D1105 diesel engine for strong and efficient performance
✔ 1,230 kg machine working weight for improved stability
✔ Rated safe load of 300 kg and maximum load capacity of 670 kg
✔ Enclosed cab for improved comfort and operator protection
✔ Dual-speed motor with travel speed up to 8 km/h
✔ Hydrostatic drive system for responsive operation
✔ Quick-change attachment compatibility
✔ Compatible with multiple buckets, forks, augers, sweepers, breakers, and specialist tools
Additional accessories, such as diggers, augers, pallet forks, rock buckets, hydraulic breakers, rotary drills, angle brooms, 4-in-1 buckets, pile drivers, fork clamps, ditch compactors, trenchers, grass clips, snow blades, and wood grabbers, can be found in the “Accessories” section on our website.
RS07 – Performance Data
| Basic Parameters | EU / US |
|---|---|
| Machine Working Weight | 1230 kg / 2706 lb |
| Bucket Capacity | 0.16 m³ / 5.65 ft³ |
| Rated Load Mass / Safe Load | 300 kg / 660 lb |
| Maximum Load Mass | 670 kg / 1474 lb |
| Travel Speed | 0–8 km/h / 0–4.9 mph |
| Gradeability | 30% |
| Ground Pressure | 95.87 kPa / 13.9 psi |
| Maximum Unloading Height | 1725 mm / 67.9 in |
| Maximum Loading Height | 2260 mm / 89 in |
| Maximum Unloading Distance | 508 mm / 20 in |
| Minimum Ground Clearance | 176 mm / 6.9 in |
RS07 – Engine Data
| Engine | Specification |
|---|---|
| Engine Brand | Kubota |
| Engine Model | D1105 |
| Maximum Horsepower | 25 ps / 24.7 hp |
| Maximum Power | 18.4 kW |
| Maximum Speed | 3000 rpm |
| Displacement | 1.123 L |
| Number of Cylinders | 3 |
| Cooling Method | Water-cooled |
RS07 – Dimensions
| Body Dimensions | EU / US |
|---|---|
| Transport Length with Bucket | 2655 mm / 104.5 in |
| Transport Length without Bucket | 1985 mm / 78.1 in |
| Transport Width | 1000 mm / 39.4 in |
| Transport Height | 1810 mm / 71.3 in |
| Bucket Width | 1000 mm / 39.4 in |
RS07 – Hydraulic System
| Hydraulic System | Specification |
|---|---|
| Main Pump Type / Model | Closed pump V90C23HT1 / RNB2S12KA1-LP01 |
| Main Pump Brand | Hengli |
| Gear Pump Brand | Tianjin Walking |
| Multi-way Valve | Pilot multi-way valve |
| Travel Motor Brand | Hengli |
Operation, Safety & Maintenance
The RS07 is designed for strong power, efficiency, and operator comfort. The cab includes adjustable seating, seat belts and bumpers for operator safety, joystick control, and a functional operator layout designed to improve control and reduce fatigue.
The RS07 uses a strengthened frame and improved boom structure for durability, while the hydraulic cylinder design helps reduce weld stress and improve reliability during demanding use.
Maintenance is designed to be easy and convenient, with rear-mounted service access, an openable rear guard, concentrated maintenance points, and accessible components and pipelines for routine inspection and repair.
Available Configuration Options
✔ Enclosed cab configuration
✔ Wheeled skid steer loader design
✔ Kubota diesel engine configuration
✔ Optional tracks / tyre configuration available depending on requirement
✔ LED lighting for improved visibility
✔ Multiple attachment options available depending on job requirements
Compatible Attachments
✔ Standard bucket
✔ Digger
✔ Auger
✔ Pallet fork
✔ Rock bucket
✔ Hydraulic breaker
✔ Rotary drill
✔ Angle broom
✔ 4-in-1 bucket
✔ Pile driver
✔ Fork clamp
✔ Ditch compactor
✔ Trencher
✔ Grass clip
✔ Snow blade
✔ Wood grabber and other specialist tools available on request
Please contact us to confirm the most suitable RS07 configuration for your project, including tyre or track requirements, bucket choice, attachment compatibility, and available accessory options.
